MIL-PRF-55310/11G
Ltr
Inches
mm
Min
Max
Min
Max
A
---
.887
---
22.53
B
---
.44
---
11.2
C
---
.27
---
6.8
D
---
.54
---
13.7
E
.145
.155
3.68
3.94
F
.295
.305
7.49
7.75
G
.295
.305
7.49
7.75
H
.595
.605
15.11
15.37
J
---
.20
---
5.1
K
.20
---
5.1
---
L
.016
.020
0.41
0.51
M
.095
.105
2.41
2.67
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerances are ±.005 (0.13 mm) for three place decimals and ±.02 (0.5 mm) for two
place decimals.
4. Case to be connected to base pin 2 to permit shielding of the oscillator.
5. All pins with NC function may be connected internally and are not to be used as external tie points or
connections.
6. Color dot or square corner shall be used to indicate pin number 1.
7. ESD indicator, open triangle, shall be marked anywhere on the top of the oscillator.
FIGURE 1. Dimensions and configuration - Continued.
