INCH-POUND
MIL-PRF-55310/11G
11 June 2009
SUPERSEDING
MIL-PRF-55310/11F
24 February 2005
PERFORMANCE SPECIFICATION SHEET
OSCILLATOR, CRYSTAL CONTROLLED, TYPE 1 (CRYSTAL OSCILLATOR (XO)),
0.05 MHz THROUGH 10 MHz, HERMETIC SEAL, SQUARE WAVE, CMOS
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein
shall consist of this specification sheet and MIL-PRF-55310.
Pin number
Function
1
OUTPUT
2
CASE
3
NC
4
NC
5
NC
6
NC
7
NC
8
B - (GND)
9
NC
10
NC
11
NC
12
NC
13
NC
14
B+
FIGURE 1. Dimensions and configuration.
AMSC N/A
FSC 5955
