MIL-PRF-3098/3G
Temperature run:
Frequency change permitted: 0.8 MHz to 2.0 MHz: ±10 ppm
2.0+ MHz to 20 MHz: ± 5 ppm
Equivalent resistance change permitted: 0.8 MHz to 2.0 MHz: ±15 percent
2.0+ MHz to 20 MHz: ±10 percent
Aging:
Frequency change permitted: ±5 ppm.
TABLE I. Equivalent resistance.
Maximum
Frequency range,
inclusive
resistance
MHz
Ohms
0.80 to 0.85
630
0.85+ to 0.90
600
0.90+ to 1.00
580
1.00+ to 1.12
540
1.12+ to 1.25
490
1.25+ to 1.37
450
1.37+ to 1.50
410
1.50+ to 1.62
380
1.62+ to 1.75
330
1.75+ to 1.87
300
1.87+ to 2.00
290
2.00+ to 2.12
270
2.12+ to 2.25
250
2.25+ to 2.60
200
2.60+ to 3.00
150
3.00+ to 3.40
110
3.40+ to 3.75
90
3.75+ to 4.00
75
4.00+ to 5.00
60
5.00+ to 7.00
35
7.00+ to 10.00
24
10.00+ to 15.00
22
15.00+ to 20.00
20
Part or Identifying Number (PIN): CR18/U (followed by specified frequency), see 1.2 of MIL-PRF-3098.
