MIL-PRF-3098/137D
REQUIREMENTS:
Dimensions, marking, and configuration: See figure 1.
Frequency range: 0.8 MHz to 20 MHz, inclusive.
Frequency tolerance: ±50 ppm.
Equivalent resistance: See table I.
TABLE I. Equivalent resistance.
Frequency range, inclusive.
Maximum resistance
MHz.
Ohms
0.80 to 0.85
520
0.85+ to 0.90
480
0.90+ to 1.00
440
1.00+ to 1.12
400
1.12+ to 1.25
380
1.25+ to 1.37
340
1.37+ to 1.50
300
1.50+ to 1.62
280
1.62+ to 1.75
250
1.75+ to 1.87
220
1.87+ to 2.00
190
2.00+ to 2.12
170
2.12+ to 2.25
150
2.25+ to 2.60
130
2.60+ to 3.00
90
3.00+ to 3.40
70
3.40+ to 3.75
52
3.75+ to 4.00
45
4.00+ to 5.00
37
5.00+ to 7.00
25
7.00+ to 10.00
20
10.00+ to 15.00
18
15.00+ to 20.00
15
Mode of oscillation: Fundamental.
Operating temperature range (noncontrolled): -55°C to +105°C, inclusive.
Rated drive level: 1.0 mW, maximum.
Resonance: Series.
Capacitance, shunt: 7.0 pF, maximum.
Shock (specified pulse):
0.8 MHz to 2.0 MHz
2.0 MHz+ to 20.0 MHz
Frequency change permitted:
±10 ppm
±5 ppm
Equivalent resistance change permitted:
±15 percent
±10 percent
2
