MIL-PRF-55310/25D
Operating: Not required.
Shock (nonoperating): Method 213 of MIL-STD-202, test condition I.
Thermal shock (nonoperating): Method 107 of MIL-STD-202, test condition B.
Ambient pressure:
Nonoperating: In accordance with MIL-PRF-55310.
Operating: Method 105 of MIL-STD-202, test condition C.
Resistance to soldering heat: Method 210 of MIL-STD-202, test condition E.
Moisture resistance: Method 106 of MIL-STD-202.
Terminal strength: Method 211 of MIL-STD-202, condition C.
Applied force: 2 pounds each terminal for 10 seconds.
Bends: 5 at 45 degrees each.
Solderability: Method 208 of MIL-STD-202.
Resistance to solvents: Method 215 of MIL-STD-202.
Screening: In accordance with MIL-PRF-55310, class B or S, as applicable.
Part or Identifying Number (PIN): Consists of "M" prefix followed by specification sheet number, a dash and coded
alphas, and numeric number. See example:
EXAMPLE
M55310/25-
B
02
A
XXXXXXXX
M prefix and specification sheet number
Product level (S, B, or C)
Dash number (see table I)
Operating temperature range
(A, B, or C) (see table I)
Frequency
Reference documents. In addition to MIL-PRF-55310, this document references the following:
8
