INCH-POUND
MIL-PRF-55310/19E
11 June 2009
SUPERSEDING
MIL-PRF-55310/19D
24 February 2005
PERFORMANCE SPECIFICATION SHEET
OSCILLATOR, CRYSTAL CONTROLLED, TYPE 1 (CRYSTAL OSCILLATOR (XO)),
1.0 MHz THROUGH 60.0 MHz, HERMETIC SEAL, SQUARE WAVE, TTL
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein
shall consist of this specification sheet and MIL-PRF-55310.
Pad number
Function
4
B+
10
B+
31
GND
37
GND
39
OUTPUT
1-3
NC
5-9
NC
11-30
NC
32-36
NC
38
NC
40
NC
FIGURE 1. Dimensions and configuration.
AMSC N/A
FSC 5955
