INCH-POUND
MIL-PRF-55310/17F
11 June 2009
SUPERSEDING
MIL-PRF-55310/17E
7 October 2004
PERFORMANCE SPECIFICATION SHEET
OSCILLATOR, CRYSTAL CONTROLLED, TYPE 1 (CRYSTAL OSCILLATOR (XO)), GATED,
250 kHz THROUGH 50 MHz, HERMETIC SEAL, SQUARE WAVE, TTL
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein
shall consist of this specification sheet and MIL-PRF-55310.
Pin number
Function
1
NC
2
NC
3
NC
4
NC
5
NC
6
NC
7
B - (GND/CASE)
8
OUTPUT
9
GATE INPUT
10
NC
11
NC
12
NC
13
NC
14
B+
FIGURE 1. Dimensions and configuration.
AMSC N/A
FSC 5955
