INCH-POUND
MIL-PRF-55310/14H
11 June 2009
SUPERSEDING
MIL-PRF-55310/14G
7 October 2004
PERFORMANCE SPECIFICATION SHEET
OSCILLATOR, CRYSTAL CONTROLLED, TYPE 1 (CRYSTAL OSCILLATOR (XO)),
0.1 Hz THROUGH 25 MHz, HERMETIC SEAL, SQUARE WAVE, TTL
This specification is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the product described herein
shall consist of this specification sheet and MIL-PRF-55310.
Pin number
Function
1
NC
2
NC
3
NC
4
B+
5
OUTPUT
6
NC
7
B- (GND/CASE)
8
NC
9
NC
10
NC
11
NC
12
NC
13
NC
14
NC
FIGURE 1. Dimensions and configuration.
AMSC N/A
FSC 5955
