MIL-PRF-3098/8G
TABLE I. Bond strength.
Frequency range,
Grams, minimum
inclusive (kHz)
200 to 250
700
250+ to 320
500
320+ to 370
400
370+ to 435
300
435+ to 555
250
TABLE II. Equivalent resistance.
Frequency range,
Maximum
inclusive
resistance
kHz
Ohms
200 to 225
2,500
225+ to 265
3,000
265+ to 290
3,500
290+ to 330
4,000
330+ to 370
4,500
370+ to 410
5,000
410+ to 425
5,500
425+ to 460
6,500
460+ to 555
7,500
Part or Identifying Number (PIN): CR18/U (followed by specified frequency), see 1.2 of MIL-PRF-3098.
Referenced documents. In addition to MIL-PRF-3098, this document references the following:
The margins of this specification are marked with vertical lines to indicate where changes from the
previous issue were made. This was done as a convenience only and the Government assumes no
liability whatsoever for any inaccuracies in these notations. Bidders and contractors are cautioned to
evaluate the requirements of this document based on the entire content irrespective of the marginal
notations and relationship to the last previous issue.
4
