MIL-PRF-3098/72F
Inches
mm
Ltr
Min
Max
Min
Max
A
---
.183
---
4.65
B
---
.435
---
11.05
C
---
.402
---
10.21
D
---
.530
---
13.46
E
.500
---
12.71
---
F
.015
.019
0.38
0.48
G
---
.150
---
3.81
H
.184
.200
4.67
5.08
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Marking to be in accordance with MIL-PRF-3098.
FIGURE 1. Crystal unit - CR97/U - Continued.
REQUIREMENTS:
Dimensions, marking, and configuration: See figure 1.
Frequency range: 8.0 MHz to 10.0 MHz, inclusive.
Capacitance, shunt: 7.0 pF, maximum.
Mode of oscillation: Fundamental.
Rated drive level: 1.0 mW maximum.
Operating temperature range (noncontrolled): -40C to +85C, inclusive.
Frequency tolerance: 50 parts per million (ppm).
Equivalent resistance: 35 ohms, maximum.
Shock (specified pulse):
Frequency change permitted: 5 ppm.
Equivalent resistance change permitted: 10 percent.
Vibration: Method 204 of MIL-STD-202, test condition A.
Frequency change permitted: 5 ppm.
Equivalent resistance change permitted: 10 percent.
2
