MIL-PRF-3098/56H
TABLE I. Equivalent resistance.
Frequency range,
Maximum
inclusive
resistance
Ohms
MHz
520
0.80 to 0.85
480
0.85+ to 0.90
440
0.90+ to 1.00
400
1.00+ to 1.12
380
1.12+ to 1.25
340
1.25+ to 1.37
300
1.37+ to 1.50
280
1.50+ to 1.62
250
1.62+ to 1.75
220
1.75+ to 1.87
190
1.87+ to 2.00
170
2.00+ to 2.12
150
2.12+ to 2.25
130
2.25+ to 2.60
90
2.60+ to 3.00
70
3.00+ to 3.40
52
3.40+ to 3.75
45
3.75+ to 4.00
37
4.00+ to 5.00
25
5.00+ to 7.00
20
7.00+ to 10.00
18
10.00+ to 15.00
15
15.00+ to 20.00
Mode of oscillation: Fundamental.
Operating temperature range:
Primary operating temperature range: -40C to +90C, inclusive.
Secondary operating temperature range: -55C to -40C, and +90C to +105C, inclusive.
Drive level, rated: 1.0 mW maximum.
Resonance: Series.
Capacitance, shunt: 7.0 pF maximum.
