MIL-PRF-3098/26H
TABLE I. Bond strength.
Frequency range,
Grams, minimum
inclusive (kHz)
190 to 250
700
250+ to 320
500
320+ to 370
400
370+ to 435
300
435+ to 500
250
TABLE II. Equivalent resistance.
Frequency range,
Maximum
inclusive
resistance
kHz
Ohms
190 to 225
5,300
225+ to 275
6,000
275+ to 325
6,500
325+ to 375
7,000
375+ to 425
7,500
425+ to 475
8,000
475+ to 500
8,500
NOTE: Frequency and resistance at room temperature (for controlled types) requirement is not
applicable.
Part or Identifying Number (PIN): CR47/U (followed by specified frequency), see 1.2 of MIL-PRF-3098.
Referenced documents. In addition to MIL-PRF-3098, this document references the following:
The margins of this specification are marked with vertical lines to indicate where changes from the
previous issue were made. This was done as a convenience only and the Government assumes no
liability whatsoever for any inaccuracies in these notations. Bidders and contractors are cautioned to
evaluate the requirements of this document based on the entire content irrespective of the marginal
notations and relationship to the last previous issue.
4
