MIL-PRF-3098/16J
Ltr
Inches
mm
Min
Max
Min
Max
A
---
.352
---
8.94
B
---
.725
---
18.42
C
.030
.037
0.76
0.94
D
.478
.494
12.14
12.55
E
---
.757
---
19.23
F
.030
.040
0.76
1.02
G
.015
.025
0.38
0.64
H
---
.317
---
8.05
J
---
.775
---
19.69
K
.223
.248
5.66
6.30
L
.048
.052
1.22
1.32
M
.075
.141
1.91
3.58
N
.015
.025
0.38
0.64
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. The pin undercut may be omitted.
4. Marking to be in accordance with MIL-PRF-3098.
FIGURE 1. Crystal unit - CR36/U - Continued.
