MIL-PRF-3098/109F
TABLE I. Equivalent resistance.
Frequency range, inclusive
Maximum resistance
Ohms
MHz
0.80 to 0.85
620
0.85+ to 0.90
600
0.90+ to 1.00
570
1.00+ to 1.12
540
1.12+ to 1.25
490
1.25+ to 1.37
450
1.37+ to 1.50
410
1.50+ to 1.62
370
1.62+ to 1.75
330
1.75+ to 1.87
300
1.87+ to 2.00
290
2.00+ to 2.12
270
2.12+ to 2.25
240
2.25+ to 2.60
190
2.60+ to 3.00
150
3.00+ to 3.40
110
3.40+ to 3.75
90
3.75+ to 4.00
75
4.00+ to 5.00
60
5.00+ to 7.00
35
7.00+ to 10.00
24
10.00+ to 15.00
22
15.00+ to 20.00
20
Mode of oscillation: Fundamental.
Temperature ranges:
Primary: -40C to +90C, inclusive.
Secondary: -55C to -40C and +90C to +105C, inclusive.
Rated drive level: 1.0 mW maximum.
Capacitance, shunt: 7.0 pF, maximum.
Antiresonance: load capacitance: 30.0 pF 0.5 pF. 1/
1/ This crystal unit is similar to Crystal Type CR-85/U, except for operation at antiresonance and
maximum equivalent resistance.
