MIL-PRF-3098/103F
Inches
mm
Ltr
Min
Max
Min
Max
A
---
.420
---
B
---
.326
---
8.28
C
---
.265
---
6.73
D
.600
---
---
E
.016
.020
0.41
0.51
F
.192
.208
4.88
5.28
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Marking to be in accordance with MIL-PRF-3098.
FIGURE 1. Crystal unit CR101/U.
REQUIREMENTS:
Dimensions, marking, and configuration: See figure 1.
Frequency range: 7 MHz to 20.0 MHz, inclusive.
Frequency tolerance: 50 parts per million (ppm).
Equivalent resistance:
7 MHz to 10 MHz: 30 ohms.
10+ MHz to 20 MHz: 25 ohms.
Antiresonance: load capacitance: 30 pF 0.5 pF.
Mode of oscillation: Fundamental.
Operating temperature range (noncontrolled): -55C to +105C, inclusive.
Rated drive level: 1.0 mW maximum.
Capacitance, shunt: 7 pF, maximum.
Shock (specified pulse):
Frequency change permitted: 5 ppm.
Equivalent resistance change permitted: 10 percent.
Thermal shock:
Frequency change permitted: 5 ppm.
Equivalent resistance change permitted: 10 percent.
2
